MICROPHONES


PINOUT MICROPHONES



PEDRO NEVADA

SETUBAL

PORTUGAL



4-PIN PRESIDENT MICROPHONE

PIN 1 - Ground

PIN 2 - Modulation

PIN 3 - TX (transmission)

PIN 4 - RX (reception)





6-PIN PRESIDENT MICROPHONE

PIN 1 - Modulation

PIN 2 - RX (reception)

PIN 3 - TX (transmission)

PIN 4 - UP/DOWN

PIN 5 - Ground

PIN 6 - Alimentation



Ob.: The picture above the microphone jack is seen in front of us and refers to the jack that is on the microphone cable.







___________________________________________________________________













MICROPHONE F/ JOPIX ITACA

MICROPHONE F/ JOPIX ITACA - Pedro Nevada







___________________________________________________________________







MICROPHONE ZETAGI MB+5

MICROPHONE ZETAGI MB+5 - Pedro Nevada







___________________________________________________________________







MICROPHONE JETFON JR-1802 F/ KENWOOD

MICROPHONE JETFON JR-1802 F/ KENWOOD - Pedro Nevada

Specifications:



- Ø speaker: 15 mm

- Output level: 72 dB

- Input power: 100 mW

- Maximum input power: 200 mW

- Speaker impedance: 32 Ω

- Type: condenser

- Sensibility: -58 dB

- Microphone impedance: 2 kΩ



Compatible





___________________________________________________________________







ADAPTER MICRO MOTOROLA GP-320/340

ADAPTER MICRO MOTOROLA GP-320/340 - Pedro Nevada







___________________________________________________________________
